Joinery IT Scratch Database

$749.00

9 customers have purchased this.

Category: , , , , Tags: , , , , , ,
  • Includes online session to train/configure Assembly Defaults (Your way)
  • Metric: Materials, Moldings, Etc
  • 5 Piece Drawers, 5 Piece Innner Drawers, Ball Bearing and Undermount Runners
  • Generic Panel and Band Materials with Assembly and Door Schedules
    • Colour, Grain, MDF, Price category, Etc
    • EG: Melteca Grain A (18-1) = 18mm Panel with 1mm Edge Band
  • Edged Door, MDF Door
    • Glass and Shaker Panel option
    • Multi-Lite Glass and Shaker Panel option
  • MDF Template Door
    • Ready for your tool-sets
  • Solid Timber Doors
    • Doors from US database, Materials from Aus/NZ
  • Finger Pull Hardware (Generic C-Rail Hardware)
    • Using new CV2021 feature
    • Pull Schedules: 30mm, 31mm, 32mm, 35mm, 36mm, 38mm, 40mm

Compatibility

  • Download for Cabinet Vision Version 2021

Other Features/Apps Included

The following features (some are apps from the CV App Store) are included on the Joinery IT "Scratch" Database

  • Adjust Parts (App installed)
  • Appliance NZ and Furnishing NZ Catalog (App installed)
  • Autoshape Corner 90 Parts (App installed)
  • Door Panel and Upper Control (App installed)
  • Euro Cabinet Assembly Construction
    • Easily convert to be "your" system by editing defaults
    • End Connection options (Default, None, Screw, Cam, Concealed - Conditions ready to go)
    • Horizontal Grain (Ends, Back, Partitions and Dividers - Conditions ready to go)
    • Split Rails/French Cleats (Upper cabinets mounted on nailer rails - Conditions ready to go)
    • Shadowline (1-Piece, L-Shaped and Hardware Channel - Conditions ready to go)
    • Top/Deck/Bottom overlay ends (Conditions ready to go)
  • Joinery IT.cvc (App included/installed)
  • Joinery IT Drawer Standards (App included/installed)
  • Joinery IT Hinge Standards (App included/installed)
  • Mitre Door Edge Finger Pull (With marker and shaped edge band - App installed)
  • Pull Positioning (Room > Cabinet > Section > Door level choices)
  • Top Stretcher Control (Vertical rotation, System 32 Brackets)
  • Shadowline (Generic Channel hardware, 46x26mm Outer Channel, 56x26mm Mid Channel)
  • Under Panels (App installed)

Additional information

Compatibility

All License Configurations CV2021

Downloads Available

Joinery IT Scratch Database for CV2021

Package Type

Database Backup and Parameters Package

Self Install

Yes
